Overview
RGB Matrix Adapter Board is a product that is convenient for users to quickly wire the RGB LED matrix panel with HUB75 interface to Raspberry Pi series motherboards and Raspberry PICO.
Specifications
-DIMENSIONS: 65mm(Length)*56mm(Width)
-POWER INPUT CONNECTOR: USB TYPE-C 5V / 4A or DC-044 5V/8A
-POWER OUTPUT CONNECTOR: Two VH-4P(3.96mm pitch) power supply connectors for RGB LED matrix panel 5V/4A
-RGB LED MATRIX PANEL INTERFACE: HUB75
-DATA INTERFACE: Raspberry Pi 40pin GPIO or Raspberry PICO connectors
Package contents:
1. RGB Matrix Adapter Board x1
2. Copper pillars x4
3. Screws x4
4. Type-C Cable x1
Notice: The Raspberry Pi in photos is NOT included.
Please feel free to contact us via Amazon message if you have any problem.
Package Dimensions : 21.41 x 8.31 x 4.6 cm; 132 Grams
Date First Available : 9 Sept. 2022
Manufacturer : XICOOLEE
ASIN : B0BC8Y447G
Guaranteed software updates until : unknown
A set of 40pin GPIO connectors for motherboards of Raspberry Pi series
A set of Raspberry PICO connectors for Raspberry PICO
Dual power input ports: USB TYPE-C 5V/4A and DC-044 5V/8A. Users can choose one of the power input ports according to their usage
Two VH-4P(3.96mm pitch) power supply connectors for RGB LED matrix panel
One HUB75 interface: It can be directly connected to the RGB LED matrix panel with HUB75 interface
